Width: Six-inch wide boards are ideal in most cases. Four inch wide material takes longer to install, creates more gaps and requires a lot more fasteners—but you can use it. Eight inch wide boards, because of their greater width, have more of a tendency to crack and cup; avoid using them.

What is the standard size for deck boards?

What Is the Standard Deck Board Size? Common deck board widths are 4”, 6” and 8”. The widths are readily available in most lumber or building supply stores, and the number of pieces easily calculated into deck dimensions. Other widths may be used for aesthetics and effect.

Can I use 1x6 for deck boards?

Width of material: We recommend only 1×4, 5/4×4 or narrower boards. Never use 1×6 or 5/4×6 material in close to ground applications. Spacing between boards: You must allow space for your deck boards to expand when they take on moisture, as they will inevitably do when exposed to wet weather, rain or high humidity.

Should I use deck boards or 2x6?

2×6 is thicker and is stronger, but is also more expensive. Spacing between deck boards provide a few critical functions. The primary function is to drain water from the deck. Gaps that are narrow (1/8”), can catch debris, specifically on top of the joists, and can be difficult to clean out.

Should deck joists be 2x6 or 2x8?

For upper-level decks, 2×10 is recommended as the minimum size to use for strong guard post connections. 2×6 joists should only be used on ground-level decks that do not require, and will not provide for, any guards. … Most decking is not strong enough to support longer spans than 16″.

What is a 5 4 deck board?

The most popular thickness for decking boards in North America is a 5/4 thickness which is an actual 1” thick. Use the table below to understand the most common board thicknesses: Decking Thickness Definition Table. Nominal Thickness.

Can you use 2x10 for deck boards?

Editor’s Comment’s: There is certainly no problem using the 2x10s for any of the structural framing of the deck. Using 2×10 treated lumber for decking is another matter entirely.

Should you leave a gap between deck boards?

Proper wood deck board spacing should have at least a 1/8 inch gap after the decking has dried out. If you install your wood or treated deck boards while they are still wet boards, then they should be attached without a gap between them.

Can you use 1 inch boards for a deck?

Certain tropical hardwoods, like Ipe, for example, are hardier than common pressure-treated woods like cedar or pine. So what size are deck boards made of different types of wood? The standard thickness for all types of wood is 1”, however, for weaker woods, choosing a thicker board can give you a sturdier feel.

Should deck boards overhang fascia?

When installing decking boards, be sure to allow for enough overhang to cover the fascia board and whatever additional amount you prefer. … This means the installed deck boards should have at least 1.75 to 2.75” overhang before the fascia is installed.

Article first time published on

How thick is a 1x6 deck board?

1x Lumber1x63/4 x 5-1/21×83/4 x 7-1/41×103/4 x 9-1/41×123/4 x 11-1/4

Do deck boards need to be pressure treated?

As long as there’s a good chance that moisture can reach the wood, it should be pressure treated. This is why the International Building Code requires that siding and structural lumber used for the last six inches of the structure above the ground is pressure treated.

What type of wood is best for a deck?

Overall, our experts at Patio Productions recommend Cedar or Redwood as the best wood choice for outdoor decks. If you’re looking for a cheaper option, pressure treated wood is your next best option.

Can I use 2x8 for deck boards?

Q: Can I use 2×8 treated lumber as deck boards? A: No, that’s a not a good idea. Lumber wider than 6 inches should not be used as a flat surface. Wide, flat boards have a tendency to pool rain water, which can lead to cupping problems.

How far can a 2x8 span for a deck?

Using this rule, a 2×6 will span 9 feet, a 2×8 will span 12 feet, and a 2×10 will span 15 feet. As you can see, the larger the depth, the longer the span.

Can 2x6 be used for deck joist?

You can use 2×6 as deck joists if the deck is low enough to the ground as not to require guard railing. When using S-P-F 2×6 deck joists, the span must not be greater than 9’0″ (2.73m) with joists at 16″ o.c. (400mm), and 9’10” (3.01m)with spacing at 12″ (300mm).

How far can a 2x10 span without support?

A 2×10 beam – made up of two 2x10s nailed together – can span up to 11′ without support beneath a deck that is 4′ wide. For a more normal-sized deck, the same beam can span 8′, supporting a deck that is 8′ wide.

Can I use 2x8 for deck joists?

2×8 for joists will be fine, with 16″ OC. Should use 2×10 for beams but 2×8 will be fine as well. If you are worried you can triple the 2×8 for the beams but double will be sufficient. You should put the beams at 7 and 14 feet out from the house, with the piers you should do 3 per beam with spacing of 1, 7, 13.

How far can a pressure treated 2x8 span?

In general, a 2×8 will span 1.5 x 8, so 12-feet. Based on all factors though, a 2×8 joist span is 7′-1” to 16′-6”, and a rafter 6′-7” and 23′-9”. In this guide, we’ll explain what span means in terms of construction, factors that impact the span, and how much weight a 2×8 can support.

How far can you span 5 4 deck boards?

Decking Board Considerations If you use 5/4 decking, joists must be no farther apart than 16 inches. Decking made of 2x4s or 2x6s can span up to 24 inches.

Can I use 5 4 deck boards?

The extra material of 2×6 boards increases the distance it can span between joists. … A 12′ (3.6m) wide deck using 5/4 deck requires ten joists for 16″ on centre spacing. The same width deck using 2×6 decking, with the larger 24″ (600mm) spacing will only require seven joists.

How thick should decking boards be?

Most composite brands have the same thickness, but softwoods and hardwoods will range from 1″ to 2″ thick for decking. Softwoods should be at least 1 1/4 inches thick for a 16″ on center span. 2 inches thick will allow for a 24″ on center span.

Is 4x2 OK for decking?

4 x 2 Timber Rail / Joist These decking joists are the most common sized framing timber for decking. They provide a solid structure for fixing your decking boards too. When making your decking frame you should use a 400mm spacing between your timber joists.

How many posts do I need for a 12x16 deck?

A standard deck will need four footings parallel to the house, but they will need to be temporarily braced by 6 inch-by-6 inch posts. Using doubled boards, you will then need to build beams on the top row of the posts to frame the edges of the deck. These must be topped with adjustable post caps.

Should you nail or screw deck boards?

The Consensus: For a deck build it’s best to use a combination of nails and screws. … Screws are superior for laying down the decking. They hold things flush better and have a better fastener/tensile strength, which keeps boards from popping up over time.

How do you stagger deck boards?

A common method for staggering a deck is to start the first row with a full plank, then cut one-third of the next row’s first board off the end. The row after that has an additional one-third cut off and then repeat when you get back to a full board.

Should deck boards be installed crown up or down?

Crown up is the preferred installation method, despite the potential for bark side down deck boards to experience shelling. Bark side down allows for the formation of a crown warp. Once the board forms a crown, there’s less potential for the wood to hold water, which could lead to the wood splintering and rotting.

How much do you overlap deck boards?

Between one and two inches of deck board overhang is ideal when you attach an outer fascia board, or at least 1 ¾” to 2 ¾” of overhang before installing the fascia.

Do I have to stagger deck boards?

If your deck dimensions are longer than your decking boards, staggering the joints is important when laying decking boards. The staggered boards improve stability and the appearance of the deck.

What does a 1x6 actually measure?

A 1×6, for example, actually measures 3/4″ x 5 1/2″. In this case, the planing is necessary for a smoother surface, so that the board could be used for interior applications. The length of the boards is generally exactly what you order, though we usually only stock pieces of even lengths.

What is the actual size of a 1x8 board?

Nominal SizeActual Size1 x 63/4 x 5 1/2 inches (19 x 140 mm)1 x 83/4 x 7 1/4 inches (19 x 184 mm)1 x 103/4 x 9 1/4 inches (19 x 235 mm)1 x 123/4 x 11 1/4 inches (19 x 286 mm)
