A vapor retarder is a material that reduces the rate at which water vapor can move through a material. The older term “vapor barrier” is still used even though “vapor retarder” is more accurate. The ability of a material to retard the diffusion of water vapor is measured in units known as “perms” or permeability.

Is vapor retarder same thing as vapor barrier?

A vapor barrier is used during the construction of a building to prevent moisture damage to the building’s fabric. Now, a vapor retarder is defined by the International Residential Code (IRC) as “a vapor-resistant material, membrane, or covering with a perm rating of 1 or less.”

Is a vapor barrier and moisture barrier the same thing?

Moisture barriers function to help in preventing water from entering inside of the wall cavity. On the other hand, vapor barriers basically prevent water vapor from the interior of the house to filter through the wall and condense on the warm side of the insulation.

What is considered a vapor retarder?

A vapor retarder is defined as a material or system that adequately retards the transmission of water vapor under specific conditions. Building occupants, certain appliances, plants, and plumbing equipment generate moisture that is carried in the air as vapor.

Why you shouldn't use a vapor barrier?

You may find that vapour barriers are often not required in warmer climates. And, if installed in the wrong climate or on the wrong side of building materials, a vapour barrier can cause more harm than good. This circumstance may prevent water vapour from drying, which in turn can cause rot and mold. (Source: Dupont.)

What is concrete vapor retarder?

Vapor retarders are materials that will minimize the transmission of water vapor from the sub-slab support system into a concrete slab. Vapor retarders are typically specified according to ASTM E 1745 and have a permeance of less than 0.3 US perms (0.2 metric perms), when tested by ASTM E 96.

What is vapor retarder used for?

Water Resistive Barriers An air barrier/vapor retarder attempts to accomplish water vapor diffusion and air movement control with one material. This type of material is most appropriate for southern climates where keeping humid outdoor air from entering the building cavities is critical during the cooling season.

Is plywood a vapor retarder?

Latex painted gypsum board (one coat of latex paint) is a Class III vapor retarder. Plywood sheathing and oriented strand board (OSB) have perm values of greater than 1 perm when using the wet cup test. … Therefore, a kraft-faced batt (Class II vapor retarder) is required on the interior of this assembly.

What does vapor diffusion mean?

Vapor diffusion is the movement of water vapor molecules through porous materials as a result of vapor pressure differences. … Stone wool vapor permeable insulation allows for greater outward drying than vapor impermeable insulation such as foam plastics.

Is vapor barrier required?

Because it is a humid climate with a lot more water vapor to worry about, a vapor barrier is often required by the building code. If the climate requires a bit more indoor heating during the year, an interior barrier is your best bet. … This is another humid climate, so vapor barriers are often required in most areas.

Article first time published on

Where should vapor barrier be installed?

Vapor barriers are usually best installed on the side of the wall that experiences the hotter temperature and moister conditions: the inner surface in colder climates and the outer surface in hot, humid climates.

Can I use plastic sheeting as a vapor barrier?

In simple terms, a vapor barrier is a material that won’t allow moisture to pass through it, such as plastic sheeting. A very simple experiment to show how a vapor barrier works is to lay a plastic garbage bag down on some damp soil. … There are two basic types of vapor barriers used with exterior wall insulation.

Does a vapor barrier let air through?

The job of a vapor barrier is to prevent vapor diffusion, and the job of an air barrier is to stop air leakage through differences in air pressure. A wall system should have one vapor barrier, but can have many air barriers.

Does drywall act as a vapor barrier?

The permeance of unpainted drywall is very high, generally between 20 and 90, so it’s not a vapor retarder at all. Meanwhile, air leakage through a 1 square inch hole in a sheet of drywall allows 30 quarts of water vapor to pass through the drywall under the same conditions.

Do I need a vapor barrier behind drywall?

Normally interior walls do not require a vapor barrier, but there are some situations where it is highly recommended. … A continuous plastic vapor barrier behind the drywall will protect the interior walls of these areas from water damage.

Should I put a vapor barrier on my ceiling?

All attics — vented or unvented — should have an air barrier (a properly detailed airtight drywall ceiling, for example) regardless of climate. Omitting a ceiling vapor barrier by arguing that “you have to let the moisture escape” or “because the house has to breathe out the top” is actually correct, in a way.

How do vapor barriers work?

A vapor barrier reduces the movement of water vapor by diffusion. Holes in the vapor barrier that allow humid air through may allow a lot more water vapor into an assembly than the vapor barrier is stopping. Because of this, air sealing is more important than vapor retarders.

What is concrete vapor barrier?

A concrete vapor barrier is any material that prevents moisture from entering a concrete slab. Vapor barriers are used because while fresh concrete is poured wet, it’s not supposed to stay that way. … If you have a concrete floor that’s in continuous contact with a source of moisture, you’re going to have problems.

What is vapor retarder in insulation?

A vapor retarder is defined as a material or system that adequately retards the transmission of water vapor under specific conditions. … The kraft facing on insulation is a vapor retarder. It can reduce moisture movement through your walls, floors, and ceilings.

Where does vapor barrier go under concrete?

In California they place sand between slabs and plastic vapor barriers—in Florida they don’t. Almost everywhere (except “California”) that slabs are placed on the ground—a plastic sheet—a vapor barrier—is located directly under the concrete slab and on top of the ground (Photograph 1).

Is vapor barrier necessary under slab?

The single most important reason you should use a high-performance vapor barrier is to protect the expensive floor covering in your building. … Water vapor diffusing through the concrete slab can also lead to deformation and discoloration of the floor covering material, leading to costly repairs or even replacement.

What can I use for vapor barrier under concrete?

The most obvious best practice is to install a sub-slab vapor barrier in the first place. I recommend a minimum 10-mil-thick polyethylene material, even if your local building code allows a 6-mil, as it lasts longer and is less prone to punctures.

What is vapor barrier in construction?

A vapor barrier (or vapour barrier) is any material used for damp proofing, typically a plastic or foil sheet, that resists diffusion of moisture through the wall, floor, ceiling, or roof assemblies of buildings to prevent interstitial condensation and of packaging.

What is a Class 2 vapor retarder?

Class II vapor retarders are typically Kraft paper (Kraft-faced insulation). The permeance of Kraft paper increases to Class III levels at higher relative humidity (from 0.3 up to 3 perms). … Typical perm ratings for common building materials are shown in Table 2. Permeance typically decreases with increasing thickness.

Is a vapor retarder designed to restrict vapor diffusion?

An air barrier/vapor diffusion retarder attempts to accomplish water vapor diffusion and air movement control with one material. This type of material is most appropriate for southern climates, where keeping humid outdoor air from entering the building cavities is critical during the cooling season.

Is Tyvek a vapor barrier?

No, DuPont™ Tyvek® is not a vapor barrier. It is made with unique material science to keep air and bulk water out while allowing moisture vapor inside walls to escape.

Do you need vapor barrier with plywood?

It is placed between the plywood and the new flooring to help reduce the moisture levels, mainly if the floor is above a crawl space. … If there is no barrier, once the plywood subfloor starts to develop moisture, the moisture can create mold, which can destroy your flooring.

Is OSB vapour permeable?

AIRTIGHT PRODUCTS Standard OSB (and other types of wood panels such as plywood, particleboard and MDF) are not suitable as an air and vapour tight layer, as their air and vapour permeability is inconsistent and can vary greatly between production cycles and manufacturing sites.

Should I use a vapor barrier in my garage walls?

Yes it is needed is you want to insulate and will be using some form of heat / ac. The vapor barrier only needs to cover the insulated area.

Do I need vapor barrier for basement walls?

Building codes usually require a vapor barrier (4 mil plastic sheeting) on exterior basement walls if the framing is attached to masonry or concrete surfaces, or if the wood framing butts up against the outer basement walls.

What side does vapor barrier go on insulation?

Vapor barriers are sheets of plastic or other material placed on one side of insulation sheets. This barrier is meant to keep moisture from getting to the insulation in the walls and ceilings, and it is required by building codes when insulating most houses. In any case, the vapor barrier must point to the warm side.
