The starting cord is wound around a spring-loaded hub that is designed to engage with the engine flywheel. When you pull the cord, the flywheel rotates, which in turn rotates the crankshaft and moves the piston. A magnetic coupling on the flywheel causes the spark plug to fire cyclically as the piston moves,.

How does a pull cord assembly work?

The operator pulls the rope’s handle or grip. This causes the rope to unwind around the crankshaft and spin it. The spinning motion of the crankshaft cranks the engine. The crankshaft’s motion engages the flywheel, enabling the engine to start.

Why is my pull cord not catching?

The pull cord mechanism on a lawn mower isn’t complicated, and the reason your cord isn’t catching is that one of the components of the flywheel starter assembly has failed under the stress of regular use. Typically it’s either worn or broken pawls, or a damaged pulley system.

How does a recoil pull starter work?

Recoil start This starter mechanism comprises a rope, with a grip at the end, moulded rope reels and a spring. … When the rope’s grip is pulled, the rope uncoils, tensions the spring, engages the clutch and turns the crankshaft, spinning it to crank or start the engine before the end of the pull stroke.

How does a pull start engine get spark?

Whether you start the engine with a pull rope or the turn of a key on an electric start motor, you’re relying on the ignition system to produce a spark inside the combustion chamber. When you start your lawn mower or small engine, you turn the flywheel and its magnets pass the coil (or armature). This creates a spark.

Why do lawn mowers need to be pulled?

Push, or walk-behind, mowers commonly feature a pulling mechanism that is designed to turn the crank shaft and start the lawn mower engine. … Understanding how the mechanism works will help when it becomes necessary to make basic repairs, including those for a broken starter cord.

How do I test my lawn mower that won't start?

  1. Loose, Dirty or Disconnected Spark Plug in Your Lawn Mower: Check it out, clean off debris, re-connect and tighten.
  2. Dirty Air Filter: Clean or replace.
  3. Fuel Not Reaching the Engine: Tap the side of the carburetor to help the flow of gas. If this doesn’t work, you might need a new fuel filter.

How much does it cost to replace a pull cord on a lawnmower?

The cost of a pull cord repair is $19.95 which includes the replacement rope. Additional parts, if needed, will be charged separately.

What causes no spark to the spark plug?

Loss of spark is caused by anything that prevents coil voltage from jumping the electrode gap at the end of the spark plug. This includes worn, fouled or damaged spark plugs, bad plug wires or a cracked distributor cap.

Why is my lawn mower turning over but not starting?

The most common reason for a riding mower cranking over but not starting is bad gas, but other possible reasons include: Gas Valve Off. No Gas. Choke Fault.

Article first time published on

Why is it hard to start my lawn mower?

The fuel filter might be clogged. A clogged fuel filter is most commonly caused by leaving old fuel in the lawn mower. … This sticky fuel can clog up the fuel filter and make the engine hard to start. If old fuel was left in the lawn mower, drain the old fuel from the fuel tank and replace the fuel filter.

Why does my lawn mower only run for a few seconds then dies?

If your lawn mower starts, runs briefly, then dies these are the four most common reasons that’s happening: Dirty carburetor / clogged carburetor bowl. Old gasoline that has gone bad. Dirty or defective spark plugs.

Can a dirty air filter cause a lawn mower not to start?

Your lawn mower’s air filter guards the carburetor and engine from debris like grass clippings and dirt. When the air filter becomes clogged or too dirty, it can prevent the engine from starting.

Where is the choke on a lawn mower?

There’s a variety of lawn mowers, but for an internal combustion engine, the choke valve is usually located on the body of the engine or a lever on the handle. Most choke valves are butterfly valves mounted in the manifold up from the carburetor jet.

How often should lawn mower spark plugs be changed?

For standard lawn mower and small engine maintenance, you should check and/or replace spark plugs: once a season. every 25 hours of use. if your lawn mower our outdoor power equipment won’t start.

What kind of spark plug does a lawn mower take?

Replacement Part TypeBriggs & Stratton Spark Plug Part NumberSpark Plug GapExtended Life Series® OHV Spark Plug Platinum (Replaces Champion RC12YC)696202 5066 (5066D, 5066H).030”Resistor Spark plug – hotter spark (Replaces Champion RC14YC)496018S 5092.030”Resistor692051.020”

What happens if you use the wrong spark plug in a lawn mower?

According to NGK, the world’s leading manufacturer of spark plugs, using the wrong spark plug can result in low ignitability within the cylinder. This causes the improper combustion of fuel, which can cause a reduced output of power as well as reduced fuel efficiency. Eventually, your engine will misfire.

Is it bad to pull a lawn mower backwards?

Simply, put, your mower will not perform as well when mowing in reverse. There are a number of reasons for this. One of the most immediately noticeable problems is that the grass will not get discharged underneath the deck. The cut is irregular, since mowing backwards means that the blades are running in reverse.

How many pulls should it take to start a lawn mower?

A lawn mower should take between three to four pulls to start. Push the mower a few times to get the wheels turning, then pull the handle quick and far back. Pulling it at the proper distance and speed is crucial for getting it to start as soon as possible.

Can a bad ground cause no spark?

Bad grounds can cause no spark issues though. It can cause the ground to ground through the ecu frying it. If you get a single spark when turning on the ignition then nothing when cranking it’s the ecu.
